Prod. # 8373A20, 750 CWP/500 WSP 1 1/2″ NPT Alloy 20 SCV® Threaded In-Line Check Valve

Description

The DFT® Model SCV is a corrosion resistant, dependable, versatile and economical spring-assisted, in-line check valve for a wide range of applications. Whether the fluid is liquid, gas or steam, the SCV provides tight shut-off and protects other equipment in the system from water hammer. Its stainless steel construction insures a long service life.

750CWP is rated to 470°F.

Download Center

Specifications
·
Materials of Construction
·
Body “O” Ring/Soft Seat Materials
·
Springs
·
Valve Selection Specifications
·
Codes and Standards
·
Features
·
Options

Specifications

Series

SCV®

Size

DN 40
1.5 in

Cold Working Pressure

0 to 750 psig
0 to 51.7 barg

Working Steam Pressure

500 psig

Dimension A

4.75 in
121 mm

Dimension B

3.44 in
87 mm

Weight

4.7 lb
2.1 kg

Cv

Cracking Pressure CP

0.24 psig
0.017 bar

End Connection

NPT

Temperature Rating¹

37 to 470 ºF
3 to 243 ºC

¹ ASME B16.34-2004

Materials of Construction

Body

A351 CN7M

Body Material

Alloy 20

Seat¹

A351 CN7M

Disc

Alloy 20

Spring

Hastelloy C276

Body Seal

Zelon (470°F max.)

¹ Soft seats are available for bubble-tight shutoff. Body seal and soft seat material are the same unless otherwise requested.

Body “O” Ring/Soft Seat Materials

Body “O” Ring/Soft Seat Materials		Seal Weld (-425 to 700°F) TFE® -Viton (-40 to 400°F) Zelon® (37 to 470°F) Buna-N (-70 to 250°F) EPDM (-75 to 300°F) Viton (-40 to 400°F)

Springs

Springs		Hastelloy C276

Valve Selection Specifications

ENDS¹

SWE Available

ASME

750 CWP
3600 CWP

Materials

316 SS/316 SS – Standard
Alloy 20 – Optional
Hastelloy® C – Optional

¹ NPT x SW available.

Codes and Standards

ANSI

B1.1
B1.20.1
B16.34

MSS

SP-126
SP-25
SP-61

ASTM¹

A351GR CF8M

¹ Contact DFT for NACE.

Features

1/2″ to 3″ Line size
750 & 3600 CWP
NPT & SW ends
Stainless Steel Construction
Inconel® X-750 spring
Spring-assisted silent closing, non-slam
Zelon® body “O” ring
Horizontal or vertical installation
Body guided disc
Tight shut-off – lapped disc & seat
Simplified construction – 5 parts
Easy maintenance
Versatile

Options

316 SS Springs
Body seal weld (700°F Maximum)
Soft seat
Alloy 20 body & seat (ASME 300)
Hastelloy C body & seat (ASME 300)
Socket weld ends
SCV-R restrictor check (higher cracking pressure)
Butt weld ends
NACE
API 6D
Light cracking pressure springs
